รายละเอียดสินค้า :

- Dimensions (L x W x H / H2 in mm):* 6.9 x 2.4 x 0.20 / 0.60 Ø 6.0 (±0.1) mm, LH = 14 (±0.2) mm (complete dimensions in application note)

- Operating measuring range: 0 m/s to 100 m/s

- Response sensitivity: 0.01 m/s

- Accuracy: < 3 % of the measured value (dependent on the electronics and calibration)

- Response time t63: ~200 ms (jump from 0 to 10000 sccm)

- Operating temperature range:* -20 °C to +150 °C

- Temperature sensitivity: < 0.1 %/K (dependent on the electronics)

- Connection:* 3 pins, AWG 30/7, stranded wire, insulated with PTFE

- Heater:* RH (0 °C) = 45 Ω ±1 %

- Reference element:* Rs (0 °C) = 1200 Ω ±1 %
